Electrolyte Analyzer T6B

产品中心 > 电解质分析仪 > Electrolyte Analyzer T6B

Electrolyte Analyzer T6B

产品详细

Features

Compact, cost efficient and easy to operate

60 tests per hour

Seal reagent kit, closed reagent system, no direct contact with liquid, easy for maintenance and transportation

Electrode for K+ ,Na+ ,Cl- ,Ca2+ and pH

Long life span, high performance, maintenance free electrodes

Original calibrator and control, real time calibration system

Automatic sampling, washing and calibration

Touch screen ,large LCD display

Internal thermal recorder

Optional Auto sampler

Specification

Measuring range & Electrolyte slope range

Electrode	Measuring range/(mmol/L)	Slope range (mV/dec)
K+	0.50~15.0	27~70
Na+	30.0~200.0	27~70
Cl-	30.0~200.0	27~70
Ca2+	0.10~5.00	15~35
pH	7.0~9.0(Unit)	27~70

Index

Parameters	Accuracy (B)	Precision (CV)	Linearity (D)	Stability (S)	Carryover (C)
K+	≤3.0%	≤1.0%	≤3.0% or ±0.08 mmol/L	≤2.0%	≤1.5%
Na+	≤3.0%	≤1.0%	≤3.0% or ±2.0 mmol/L	≤2.0%	≤1.5%
Cl-	≤3.0%	≤1.0%	≤3.0% or ±2.0 mmol/L	≤2.0%	≤1.5%
Ca2+	≤5.0%	≤3.0%	≤3.0% or ±0.04 mmol/L	≤3.0%	≤1.5%
pH	≤1%	≤2.0%	≤5.0%	≤2.0%	≤1.5%

Sample Variety:Serum, Plasma (Whole blood) or Urine

Measuring Speed:60 samples/hour

Environment requirement Ambient temperature:(10~30)°C; Relative humidity:(20~85) %; Atmospheric pressure:(86~106)kPa; Avoid electrical interference;

Avoid direct sunlight Correctly grounding

Power supply: AC220/110V±10%, 50/60 Hz

Output Method: LCD with backlight, printer

Power consumption: 60VA

Dimension: 440mm(L) x410mm(W) x 510mm(H)

Weight:

Main unit 7.2kg; Gross weight 12.2kg;

Auto sample plate 1.5kg
